Maintenance & Safety Guidelines

General Safety Guidelines

  • Do not spill liquids on the body of the device.
  • Never operate the device in a wet environment.
  • Keep the device away from radiators and heat sources.
  • Use the device only with the accessories supplied.
  • Do not alter the device or open enclosures.

Warning Notice

If any of the following conditions occur, unplug the device from the electrical outlet and contact authorized service personnel:

  • The power cord or power adapter is damaged.
  • The device has been exposed to water.
  • The device has been damaged.
  • The device does not operate correctly when the operating instructions are followed.
  • Cleaning the Scanner



The handpiece, base and cord of the scanner must be wiped down using an approved disinfectant that is labeled and specified for tuberculocidal/mycobactericidal activity.

Cleaning the Scanner: Important Precautions

  • Do not autoclave the handpiece of the device.
  • All components of the scanner must be wiped down and not sprayed.
  • Avoid getting any moisture, alcohol or disinfectant inside the open scanner chamber.
  • Do not use disinfectant on the nozzle/tip.
  • Recommended and approved surface disinfectants

  • Birex Wipes: TB Claim=10 minutes-‘Phenolic (Dual) Water-Based’

  • Prospray Wipes: TB Claim=10 minutes-‘Phenolic (Dual) Water-Based’

  • Cavicide Wipes: TB Claim=3 minutes-‘Phenolics (Dual) Alcohol-Based’

  • DisCide ULTRA Wipes: TB Claim=1 minute-‘Phenolics (Dual) Alcohol-Based’

  • Maxiwipe Germicidal Cloth: TB Claim=5 minutes-‘Phenolics (Dual) Alcohol-Based’

  • Ster1 Plus: TB Claim=5 minutes-‘Quaternary ammonium and Alcohol-Based’

Cleaning and Sterilizing the Removable Tips

For instructions on cleaning and sterilizing the removable tip of the scanner, go to:

Cleaning and Sterilizing the Scanner Tip

Important Safety Notices

When sterilizing the removable tips...

  • Always autoclave the tip wrapped in a sealed sterilization pouch: failure to do so will result in permanent stains on the mirror.

  • Tips should not be placed in an ultrasonic cleaner or cold sterile solution. The sterilant will leave a sticky residue or film on the mirror when drying.

  • Do not remove the pouch before the sterilizer completes the full dry cycle.

    If the pouch is wet or has any signs of moisture, this can potentially leave water spots on the mirror that can affect image quality during scanning.
